MIL-PRF-49318A(CR)
4.3 Conformance inspection.
4.3.1 Inspection. Each Assessor and associated adapters shall be inspected to the
requirements of Table I in process and when assembled as applicable. Presence of one or more
defects shall be cause for rejection of that component or attachment.
4.3.2 Tests.
4.3.2.1 Group A inspection. Each Assessor and adapter shall be tested in accordance with
Table III. Each Assessor shall have been subjected to and passed Environmental Stress
Screening (ESS) as specified in 3.11. The tests listed Table III may be performed in any order.
Failure of an Assessor or adapter to pass any tests shall be cause for rejection of that Assessor or
adapter. Units which pass the Group A test shall be formed into lots by the contractor.
TABLE III. Group A inspection.
Inspection
Requirement paragraph
Test paragraph
Resolution target
3.5.2
4.5.2
Light levels
3.5.1
4.5.1
4.3.2.2 Group B inspection. Assessors and adapters which have successfully passed
Group A tests shall be sampled and subjected to the tests prescribed in Table IV. Sampling shall
be in accordance with the contract or purchase order (see 6.2.f).
TABLE IV. Group B Inspection.
Inspection
Requirement paragraph
Test paragraph
Low battery Indicator
3.5.6
4.5.6
Output collimator
3.5.3
4.5.3
Weight
3.3.3
Visual
4.3.2.3 Group C inspection. Group C inspection shall be conducted on lots that have
successfully passed Group A tests. Sampling shall be in accordance with the contract or
purchase order (see 6.2.f).
TABLE V. Group C inspection.
Inspection
Requirement
Inspection
Subgroup
paragraph
paragraph
1
2
High Temperature
3.6.1
4.6.1
X
Low Temperature
3.6.2
4.6.2
X
Altitude
3.6.3
4.6.3
X
Temperature shock
3.6.4
4.6.4
X
Shock
3.6.5
4.6.5
X
Vibration
3.6.6
4.6.6
X
10
