MIL-PRF-49446B(CR)
4.2 First article inspection. When specified in the contract, first article inspection shall
be performed by the contractor on a minimum of five (5) preconditioned (see 3.9) sample
Detectors-Dewar. This inspection shall include the visual examination of 4.2.1 and the tests of
4.2.2 through 4.3. Refer to the contract for specific instructions regarding first article inspection
(see 6.2).
4.2.1 Visual examination. All completed assemblies shall be examined for conformance
to the applicable specifications or drawings (See Table I)..
TABLE I. Inspections.
Inspection
Requirement
Dimensions not as specified
3.3.1
Any as specified part or component
missing or damaged
3.3.1
Weight not specified
3.3.2
Getters and label not
as specified
3.4
Detector orientation range
not specified
3.4
Sensitive area not as specified
3.5.3
Dewar warm and cold shields
not as specified
3.5.11
Treatment and painting
not as specified
3.8
Marking not as specified
3.10
Workmanship not as specified
3.11
4.2.2 Tests. First article inspection shall be conducted upon units which have
successfully completed the inspections specified in 4.2.1. Tests may be conducted in any order,
except that microphonics shall be performed after the shock and vibration test (see 4.6.4 and
4.6.5).
7
