MIL-PRF-49176B(CR)
manufacture of complete systems or subassemblies thereof if these systems are subjected
to equivalent preconditioning.
h. Environmental pollution prevention measures are contained in the packaging
material specifications or provided by preparing activity for recommended
disposability.
i. Issue of DoDISS to be cited in the solicitation, and if required, the specific issue of
individual documents referenced (see 2.2.1, and 2.3).
6.3 Definitions.
6.3.1 Damage. Breakage, loosening, shifting, evidence of corrosion, or failure of any finish,
hardware, connection or component; and any degradation of regular performance to values less
than specified herein.
6.4 Environmental inspection procedures. The test methods and procedures of
MIL-STD-810, listed below, are recommended, but are not mandatory for determining compliance
with the environmental requirements of this specification.
TABLE V. Environmental inspection procedures.
Req.
MIL-STD-810
MIL-STD-810
MIL-STD-810
Inspection
Para.
Method
Procedure
Remarks
Temperature
3.6.1
503
I
Non-operating mode. In step 2
use -54°C, and for step 1 and 4
shock
use +95°C
High temperature
3.6.2
501
I
Test simultaneously with
(see Figure 3)
paragraph 3.5.2, for final 30
minutes of step 3. For step 2
use +95°C and Steps 4 & 5 use
+71°C
Low temperature
3.6.3
502
I
Test simultaneously with
(see Figure 4)
paragraph of 3.5.2, in lieu of
Table III inspection. For step 2
use -62°C and step 4 use -54°C.
Shock
3.6.4
516.1
IV, V
Non-operating mode.
Vibration
3.6.5
514.1
I, VIII
Non-operating mode. Use
(see Figure 1)
Figure 1 (page 11) in lieu of
MIL-STD-810 curve.
Sinusoidal cycle time shall be
120 minutes per axis. Dwell
time shall be 1/6 of the cycling
time at each resonance.
12
