MIL-PRF-49176B(CR)
4.2 First article testing. When specified in the contract, the first article inspection shall be
performed by the contractor as specified in the contract. First article reliability (4.2.3) is not
required unless specified in the contract (see 6.2.b.3).
4.2.1 Inspections. All materials, parts, processes and assemblies shall be visually examined
for conformance to the applicable specification or drawing and Table I inspections. Inspection
shall be made using sampling per ASQC Z 1.4.
TABLE I. Visual inspection.
Inspection
Requirement paragraph
Test paragraph
Any part or component
3.4
missing or damaged
4.2.1
Dimensions not as specified
3.4
Length
4.2.1
Width
Weight not as specified
3.4.1
4.2.1
Coating not as specified
3.8
4.2.1
Soldering not as specified
3.10
4.2.1
Marking not as specified
3.11
4.2.1
Workmanship not as specified
3.12
4.2.1
* In ASQC Z 1.4 use inspection level S-3 for objective quality evidence.
4.2.2 Tests. Upon successful completion of inspections specified in 4.2.1, perform the
inspections of Table II in any order.
TABLE II. First article inspection.
Inspection
Requirement paragraph
Test paragraph
Output noise
3.5.1
4.5.1
Output voltage and output current
3.5.2
4.5.2
Current limit
3.5.3
4.5.3
Line rejection
3.5.4
4.5.4
Output impedance
3.5.5
4.5.5
Temperature shock
3.6.1
4.6.1
High temperature
3.6.2
4.6.2
Low temperature
3.6.3
4.6.3
Shock
3.6.4
4.6.4
Vibration
3.6.5
4.6.5
Reliability
3.7
4.7
4.2.3 First article reliability. The lower inspection MTBF (θ1) shall be demonstrated in
accordance with the following subparagraphs:
6
