MIL-PRF-49177B(CR)
TABLE II. First article inspection.
Inspection
Requirement paragraph
Test paragraph
Power consumption
3.5.1
4.5.1
Identification resistor verification
3.5.2
4.5.2
Regulator voltage
3.5.3
4.5.3
Start-up electronics
3.5.4
4.5.4
Scan transducer amplifiers
3.5.5
4.5.5
Sync drive
3.5.6
4.5.6
Spring limit pulse width
3.5.7
4.5.7
Scan rate
3.5.8
4.5.8
Scan drive
3.5.9
4.5.9
Scan motor drive amplifier
3.5.10
4.5.10
Interlace transducer amplifier
3.5.11
4.5.11
Interlace position reference
3.5.12
4.5.12
Interlace rate reference
3.5.13
4.5.13
Interlace position error
3.5.14
4.5.14
Solenoid drive amplifiers
3.5.15
4.5.15
Video gate
3.5.16
4.5.16
Transducer bridge voltage
3.5.17
4.5.17
Scan fail electronics
3.5.18
4.5.18
Temperature shock
3.6.1
4.6.1
High temperature
3.6.2
4.6.2
Low temperature
3.6.3
4.6.3
Shock
3.6.4
4.6.4
Vibration
3.6.5
4.6.5
Reliability
3.7
4.7
4.2.3 Disposition of first article samples. First article samples shall not be considered as
part of the procurement quantities (see 6.2.g).
4.3 Inspection conditions. Unless otherwise specified herein, the Scan-Interlace shall
meet the specified performance requirements at an ambient temperature of +23°C, ±5°C.
4.3.1 Input power. The Scan-Interlace shall operate with the following voltages and
currents:
a. Plus 5.0, + 0.3 volts direct current (Vdc) (1.0 ampere peak), 0.65 rms watt maximum
b. Minus 5.0, ±0.3 Vdc (1.0 ampere peak), 0.25 rms watt maximum
c. Plus 15.0, ±0.5 Vdc and -15.0, ±0.5 Vdc (1.5 amperes peak), 6.6 rms watts maximum
10
