MIL-PRF-49168C(CR)
4.2.1 Inspections. All materials, parts, processes and assemblies shall be visually examined
for conformance to the applicable specification or drawing. Inspections shall be made using
ANSI/ASQC Z 1.4 sampling procedures. Sample size shall conform to ASTM E 122-89 as cited
in the contract or purchase order (see 6.2).
TABLE I. Visual Inspections.
Inspection Requirement
Requirement paragraph
Inspection criteria
Any part or component
3.3
4.2.1
missing or damaged
Weight not as specified
3.3.2
4.2.1
Coating not as specified
3.8
4.2.1
Soldering not as specified
3.10
4.2.1
Marking not as specified
3.11
4.2.1
Workmanship not as specified
3.12
4.2.1
Dimensions not as specified
3.3
4.2.1
Length
Width
Height (maximum)
Solder/lead protrusion
Pins (connector location)
Pins (guide location)
4.2.2 Tests. Upon successful completion of inspections specified in 4.2.1, perform the
tests of Table II in any order. Failure of any tests shall constitute first article failure.
8
