MIL-PRF-49168C(CR)
TABLE II. First article inspection.
Inspection
Requirement
Test
paragraph
paragraph
paragraph
Power consumption
3.5.1
4.5.1
Identification resistor
3.5.2
4.5.2
verification
Regulator voltage
3.5.3
4.5.3
Transducer bridge voltage
3.5.4
4.5.4
Scan motor drive circuitry
3.5.5
4.5.5
Interlace position amplifier
3.5.6
4.5.6
Position reference circuitry
3.5.7
4.5.7
Position error circuitry
3.5.8
4.5.8
Rate reference circuitry
3.5.9
4.5.9
Solenoid drive circuitry
3.5.10
4.5.10
Video gate
3.5.11
4.5.11
Side/rear phasing
3.5.12
4.5.12
Temperature shock
3.6.1
4.6.1
High temperature
3.6.2
4.6.2
Low temperature
3.6.3
4.6.3
Shock
3.6.4
4.6.4
Vibration
3.6.5
4.6.5
Reliability
3.7
4.7
4.2.3 Disposition of first article samples. First article samples shall not be considered as
part of the procurement quantities (see 6.2).
4.3 Inspection conditions. Unless otherwise specified herein, the assembly shall meet the
specified performance requirements at ambient temperature (see 6.4.2).
4.3.1 Test power supplies. The test power supplies shall provide the voltages as specified
in 3.5.1.
4.3.2 Supply ripple. The supply ripple shall not be greater than 0.1 volts P-P for the +4.8
Vdc supplies, and shall not be greater than 0.2 volt P-P for the +/-100.0 Vdc supplies.
4.3.3 Supply rise time. The supply rise times shall not be greater than 0.5 seconds.
4.3.4 Supply tracking. Turn-on rise times of the ±10.0 Vdc power supplies shall not be
greater than that of the ±4.8 Vdc power supplies. The rise times of the ±4.8 Vdc power supplies
shall track within 20 percent.
9
