MIL-PRF-49169B(CR)
4.2.1 Inspections. All materials, parts, processes and assemblies shall be examined for
conformance to Table I Inspections and the sampling plan of Table I-1.
TABLE I INSPECTIONS
INSPECTION REQUIREMENT
REQ'T
INSPECTION
PARA
CRITERIA
Array burn-in*
3.5
4.2.1
Emitting area*
3.6.6
4.5.6
Weight not as specified
3.2.1
4.9
Marking not as specified
3.9
4.8
Workmanship not as specified
3.10
4.8
Dimensions not as specified*
3.2
Drawings
- Diameter, interface (2.001" ref)
SM-D-806557
- Holes (4) thru cover, location
5002475
- Mark, alignment, location
5002478
- Pins, connector, location
- Field flattener lens
*Inspect every array 100 percent.
TABLE I-1 Sampling Plan for Inspection.
Lot Size
Sample Size
2
2 to 8
3
9 to 15
5
16 to 25
8
26 to 50
13
51 to 90
20
91 to 150
4.2.2. Tests. Upon successful completion of the inspections specified in 4.2.1, perform the tests
of Table II in any order. Prior to start of tests specified in Table II, LED modules shall be
identified as to their applicable subgroups. Unless otherwise specified in the contract (see 6.2),
three units shall be tested in subgroup 1 and three units in subgroup 2. Failure of any tests on any
unit shall constitute first article failure.
4.2.3 Disposition of first article samples. First article samples shall not be considered as part of
the procurement quantities.
6
