MIL-PRF-49167B(CR)
3.5 Performance characteristics.
3.5.1 Input power. The auxiliary control module shall operate from the supply voltages
and current input power within the supply current limits as follows:
High power mode
Low power mode
Supply voltage
Max supply current
Supply voltage
Max supply current
(Vdc)
(mA)
(Vdc)
(mA)
+10.0 ± 0.2
+4.8 ± 0.1
660
540
-7.5 ± 0.2
-4.8 ± 0.1
660
540
+7.0 ± 0.1
15
-7.0 ± 0.1
15
3.5.2 IR level and gate output. IR level and gate output shall be a rectangular waveform
of +1.0 ±0.1 vdc and 0 to -1.5 ±0.1 vdc as shown in figure 1.
3.5.3 IR gain command voltages. The gain command voltage outputs for the auxiliary
control module shall have a minimum adjustable range as listed:
Gain command voltages
High power mode
Low power mode
Gain command 1
Adjustable from
Adjustable from
-3.5 to +3.5Vdc
-2.0 to +2.0 Vdc
Gain command 2
Adjustable from
Adjustable from
-3.5 to +3.5Vdc
-2.0 to +2.0Vdc
3.5.4 Regulator output voltages. The positive and negative regulator outputs shall have a
minimum adjustable range as listed:
Regulator output voltages
High power mode
Low power mode
Positive regulator output
Adjustable from
Adjustable from
+3.0 to +4.5Vdc
+3.0 to +3.5
Negative regulator output
Adjustable from
Adjustable from
-3.0 to -4.5Vdc
-3.0 to -3.5 Vdc
The positive and negative regulator output voltages, when fixed in the high power mode at +4.25
Vdc and -4.25 Vdc respectively, shall not vary by more than ±0.25 Vdc over the temperature
range of -54°C to +71°C.
