MIL-PRF-49167B(CR)
TABLE I. Inspections.
Inspection Requirement
Requirement
Inspection
paragraph
criteria
Any part or component missing or
3.2
MIL-STD-252(Used as
guide)
damaged
Weight not as specified
3.4
MIL-STD-252(Used as
guide)
Soldering not as specified
3.10
MIL-HDBK-454(Used as
guide)
Marking not as specified
3.11
MIL-M-13231(Used as
guide)
Workmanship not as specified
3.12
MIL-HDBK-454(Used as
guide)
Coating not as specified
3.8
Dimensions not as specified
3.3
SM-D-773888
Length and width
Dimensions not as specified
3.3
SM-C-773501
Height, max, Solder/lead
protrusion
Dimensions not as specified
3.3
SM-C-773541
Pins, connector location
Pins, guide location
4.2.4 Tests. Upon successful completion of inspections specified in 4.2.3, perform the
tests of table II. Failure of any test shall constitute failure of first article inspection.
TABLE II. First article inspection.
Inspection
Requirement
Test
paragraph
paragraph
Input power
3.5.1
4.4.1
IR level & gate output
3.5.2
4.4.2
IR gain command voltages
3.5.3
4.4.3
Regulator output voltages
3.5.4
4.4.4
IR polarity control outputs
3.5.5
4.4.5
Polarity transient suppression
3.5.6
4.4.6
Scan failure protect
3.5.7
4.4.7
Temperature shock
3.6.1
4.5.1
High temperature
3.6.2
4.5.2
Low temperature
3.6.3
4.5.3
Shock
3.6.4
4.5.4
Vibration
3.6.5
4.5.5
Reliability
3.7
4.6
7
